Fiber Network Products, Fiber Optic Couplers
Adapter Panel (12) LC OM4 with Pigtails (760109470)
Adapter Panel (12) LC OM4 with Pigtails
Compare
Specifications:-
Product Classification:-
| Regional Availability | Asia | Australia/New Zealand | EMEA | Latin America | North America |
| Portfolio | CommScope® |
| Product Type | Fiber cassette with pigtails |
| Product Series | G2 |
General Specifications:-
| Color, front | Aqua |
| Intelligence Type | iPatch® ready |
| Interface, front | LC |
| Shuttered | No |
| Total Ports, quantity, front | 12 |
Dimensions:-
| Height | 25.908 mm | 1.02 in |
| Width | 94.996 mm | 3.74 in |
| Depth | 123.012 mm | 4.843 in |
Optical Specifications:-
| Fiber Mode | Multimode |
| Fiber Type | OM4 |
| Insertion Loss, maximum | 0.33 dB |
Environmental Specifications:-
| Qualification Standards | IEC 61753-1 | TIA-568.3-D |
| Safety Standard | CE | CSA | UL |
Packaging and Weights:-
| Packaging quantity | 1 |
| Weight, net | 0.098 kg | 0.215 lb |
